Stevia Leaves Drying Machine
Versatile and widely used for drying grain materials,fruit,herb, vegetables etc.
24-hour continuous working avoiding heat waste.
Fully auto and labor saving, 1-2 workers can operate.
Large capacity.
Heat source can be freely chosen according to the local situation. Wood, coal, biomass granules, steam, natural gas, diesel, air chamber (electricity), etc.
Product Description
Stevia is a special plant with high sweetness and low energy, containing many beneficial ingredients for the human body. It can not only be used as a natural sugar, but also for medicinal purposes. In recent years, with the increasingly widespread application of stevia sugar, the market has shown a good development momentum. The assembly line Stevia rebaudiana dryer has the characteristics of high intelligence and high efficiency, and has been supported by a large number of food processing plants and tea processing enterprises.
Ⅰ.Construction of Stevia Leaves Drying Machine：
Multi-layer belt dryer mainly consists of a slow-moving stainless steel mesh belt (usually 5 layers, adjustable based on client’s needs ), frame, insulated board shell and a heat source.Partitions are set between the layers to organize the directional flow of the drying medium and make the material dry evenly. The multi-layer belt dryer occupies less land and has a simple structure. Coal, wooden pellets, gas, electricity etc is optional as heating source.
Ⅱ.The principle of Stevia Leaves Drying Machine:
The stevia is transported to the top layer of the mesh belt by a conveyor belt.The dryer main body is composed of 3-7 layers of stainless steel mesh belts, driven by chains on both sides, and equipped with baffles on both sides of the mesh belt to prevent materials from falling into the middle of the track. Hot air is provided by energy-saving hot air furnaces that burn coal (or wood, electricity, gas, etc.). The hot air is sent by a blower to the bottom of the dryer, where it first exchanges heat with the drying material through the bottom mesh belt, taking away some moisture, and then passes through layer by layer. The mesh belt forms a countercurrent heat exchange with the material. After the wet air reaches the upper layer and undergoes heat exchange with the wet material, it is basically saturated, enters the dehumidification outlet, and is discharged outdoors by humidity emitting fans.Following heat source is optional according to your local fuel.
Ⅲ.Advantages of Stevia Leaves Drying Machine：
- 01Stevia leaf dryer is widely used for dehydration and drying of various regional and seasonal vegetables and fruits. Such as pepper, camellia seed, konjac, white radish, yam, bamboo shoot and so on.
- 02The equipment is easy to operate and easy to maintain. The average worker can operate it in one day after learning it.
- 03Long service life and low maintenance costs,High degree of intelligence, 24-hour continuous drying operation.
Technical Parameters
|
Model |
JL-2*7 |
JL-2*10 |
JL-2*20 |
|
Layer numbers |
Five layers, six layers, seven layer optional |
||
|
Shell thickness |
50mm |
||
|
Belt width |
2m |
||
|
Drying area (m2) |
70 |
100 |
200 |
|
Loading capacity (kg/m2) |
10-40 |
||
|
Running speed (m/min) |
0.4-4 adjustable |
||
|
The above parameters are for reference,we can provide suitable solution according to customer's requirements. |
|||
