Hawthorn Dryer
Versatile and widely used for drying grain materials,fruit,herb, vegetables etc.
24-hour continuous working avoiding heat waste.
Fully auto and labor saving, 1-2 workers can operate.
Large capacity.
Heat source can be freely chosen according to the local situation. Wood, coal, biomass granules, steam, natural gas, diesel, air chamber (electricity), etc.
Product Description
Fresh hawthorn is dried into hawthorn slices for easy storage and transportation. Helps promote digestion, helps the body absorb more nutrients, and supplements rich carbohydrates and proteins.
Ⅰ.Construction Of Hawthorn Dryer:
The mesh belt dryer consists of a feeder conveyor, an equally distributed bar for material distribution, a main drying body with 5-7 layers of stainless steel mesh belts, optional heat source, a centrifugal fan for hot air circulation, humidity exhaust fans, an output conveyor belt, gear-drive equipment, and panel control. The width of the mesh belt dryer is 2-3 meters,while the length and number of layers can be customized according to the client's capacity. Usually, it is recommended to have a length of at least 7 meters for cost-effectiveness.
Ⅱ.Working Principle Of Hawthorn Dryer:
The hawthorn is transported to the top layer of the drying body through a belt conveyor and then falls onto the mesh belt. With the continuous movement of the mesh belt,the hawthorn undergoes dynamic drying as it moves from the top layer to the bottom without any interruptions.During this process, the hawthorn is automatically reversed each time it falls onto the lower layer, which accelerates the drying process. Compared to other drying machines, the mesh belt dryer requires less time to dry the same materials.Following heat source is optional according to your local fuel.
Hawthorn is introduced from the upper section, and the thickness of the hawthorn layer is regulated by the automatic spreading device. Propelled by the mesh belt, the hawthorn progresses from the upper part to the lower part. During operation, the hawthorn experiences multiple falls, ensuring thorough turning and even drying. The dried hawthorn is discharged through the lower outlet, allowing for extensive contact with high-temperature hot air and achieving the desired drying outcome.
Ⅲ.Advantages Of Hawthorn Dryer:
- 01Efficient and rapid drying process with a short cycle and high output, while ensuring no pollution.
- 02Uniform and sufficient heat and mass exchange for optimal drying results.
- 03Versatile functionality, allowing for multiple purposes and cost and space savings.
Technical Parameters
| Model | JL-1*10m | JL-1*12m | JL-1*17m |
| Layer | 3layersm,4 layers,5 layers,6 layers,7 layers | ||
| Material thickness | 50-200mm | ||
| Drying temperature | 40-120℃ | ||
| Drying time | 0.5-5hours | ||
| Moisture reduce | 75%-80%(customized) | ||
| Main equipment motor | 2.2kw | 2.2kw | 2.2kw |
| Hot air draft fan | 10C-15.5KW | 10C-18.5KW | 12C-30KW |
| Materials discharge conveyor | 0.12KW(Gear speed regulating motor) | ||
| The above parameters are for reference,we can provide suitable solution according to customer's requirements. | |||
